TM3000F Positive and negative pressure membrane press machine
Features
1.Fast speed: 3 meters worktable is high efficiency and more cost saving.The working period of ordinary workpiece is less than 2 minutes after it enters the main machine, which is 2-4 times of the efficiency of common positive and negative pressure membrane pressure equipment.
2.Good effect: the product processed by common film has clear groove, no open side, bubbling, no color difference, and high light working surface has strong adhesion, and the effect reaches the international leading level.
3.Low energy consumption: the total power of the machine is 35KW, which is one half of that of the peer equipment; The main heating starting power is 21KW, and the average power consumption is 12KW/h.
4. High configuration: the key part of the machine adopts original parts from Germany, Japan and Taiwan, which is high configuration and stable performance.
Outline size 12200mm*2150mm*2480mm
Worktable size 3000mm*1270mm
Weight 17T
Total power 35kw
Actual power consumption About 12kw
Maximum processing size 50mm
Voltage 380v 50HZ optional
Rated operating pressure positive ≤0.6Mpa negative ≥-0.095Mpa
